Page #14 background image
14 | SAMLEX AMERICA INC.
SECTION 6 | Specications
PARAMETER SPECIFICATIONS
Electrical
Nominal Battery System Voltage 12V
Rated Charge / Discharge Current 10A
Minimum Battery Voltage to Start Controller 6V
Self Consumption ≤ 8.4mA
Temperature Compensation 18mV/°C (With built-in Temperature Sensor)
Battery Charging NOTES: (i) Specications are for Sealed / AGM Lead Acid Battery
(ii) All voltage specications are at 25°C
Type of Lead Acid Battery Sealed, AGM
Bulk Charge Current
Equal to instantaneous Short Circuit Current
Isc of the Solar Array
Absorption (Boost) Stage Voltage, “Va” 14.4V
Absorption (Boost) Stage Duration 2 Hrs
Equalization Stage Voltage, “Ve” 14.6V
Equalization Stage Duration 2 Hrs
Condition for Executing Equalization Cycle Battery Voltage drops to 10.8V
Float Voltage, “Vf” 13.8V
Exit to Absorption (Boost) when in Float Stage 13.2V
Under Voltage Warning 12.0V (LED Battery Status Indicator Orange)
Under Voltage Warning Auto Reset 12.2V
Over Voltage Limit ≥15.5V (Charging Stops)
Over Voltage Limit Auto Reset ≤ 15.0V (Charging Resumes)
Over Voltage Disconnect Indication 16.0V
Control on Load Terminals
Low Battery Disconnect 11.1V
Low Battery Reconnect 12.6V
Environmental
Operating Temperature -35°C to +55°C
Storage Temperature -35°C to 80°C
Humidity ≤95% Non Condensing
Ingress Protection (IP) Rating
IP-30 (Protected against ingress of objects >
2.5mm; Not protected against ingress of water)
Mechanical
Input Output Connections Moving Cage Type, 4mm
2
/AWG#12
Compliance
Electro Magnetic Compatibility
CE Marked – Conformity with EMC Directive
2004/108/EC
Note: Specications are subject to change without notice.
SPECIFICATIONS OF CHARGE CONTROLLER - MSK-10A
