8 | SAMLEX AMERICA INC. SAMLEX AMERICA INC. | 9
SECTION 4 | Installation & Operation
WARNINGS & CAUTIONS!
PLEASE READ ALL THE SAFETY INSTRUCTIONS GIVEN IN SECTION 1 BEFORE INSTALLING
AND OPERTING THE KIT. FAILURE TO ABIDE BY THE RECOMMENDATIONS MAY CAUSE
PERSONAL INJURY / DAMAGE TO THE KIT.
Do not use the unit in wet environment
Please note that the solar modules are waterproof (IP-65). However, the Charge Con-
troller MSK-10A attached at the back of one of the modules is not waterproof (IP-30).
Hence, please ensure that the kits are installed in dry environment.
OVERALL CONNECTION ARRANGEMENT - SOLAR PANELS, CHARGE
CONTROLLER, BATTERY AND LOAD
Fig 3.1 shows overall connection arrangement of the panels, Charge Controller, battery
and load. Fig 3.2 shows layout of Charge Controller.
Connection Arrangement of Solar Panels to the Charge Controller
The 3 panels are already connected in parallel to the PV+ and PV- terminals of the
Charge Controller (Fig 3.2) through their respective Junction Boxes (6 - Fig 3.1). No ad-
ditional connection is required to be made.
Connection of Battery or Battery Bank to the Charge Controller
The following arrangement has been provided for connecting the Charge Controller to
the battery:
Battery Terminals of the Charge Controller (Fig 3.2) are prewired to 14ft cable with
2-Pole, 50A Mating Type Battery Connector (8A, Fig 3.1) through 10A Fuse and Fuse
Holder (11, Fig 3.1)
2 ft. Adaptor Cable (9, Fig 3.1) with 2-Pole, 50A Mating Type Battery Connector (9A,
Fig 3.1) on one end for connecting to the mating connector on the Charge Control-
ler side (8A, Fig 3.1). Battery clamps (9B, 9C - Fig 3.1) are provided on the other end
for connecting to the battery.
2 ft. Adapter Cable (10, Fig 3.1) with 2-Pole, 50A Mating Type Battery Connector on
one end (10A, Fig 3.1) on the Charge Controller side and SAE Connector (10B, Fig
3.1) on the other end to mate with corresponding SAE mating connector for Bat-
tery charging inlet connection provided on some RV's.
!
