SamplexPower MSK-90 User Manual

12 | SAMLEX AMERICA INC. SAMLEX AMERICA INC. | 13
SECTION 6 | Specications
PARAMETER MSK-135 MSK-90
SOLAR ARRAY
NOMINAL MAXIMUM POWER AT
STC, Pmax
135W
(3 x 45W Panels ±3% in
parallel)
90W
(3 x 30W Panels ±3% in
parallel)
MAXIMUM POWER VOLTAGE,
Vmp
17.5V 17.5V
MAXIMUM POWER CURRENT, Imp 7.71A
(2.57A per 45W Panel)
5.13A
(1.71A per 30W Panel)
OPEN CIRCUIT VOLTAGE, Voc 21.6V 21.6V
SHORT CIRCUIT CURRENT, Isc 8.34A
(2.78A per 45W Panel)
5.55A
(1.85A per 30W Panel)
TYPE OF CELLS / SIZE Monocrystalline
NUMBER OF CELLS 36 Cell per Panel
MAXIMUM SYSTEM VOLTAGE 1000 VDC
OPERATING TEMPERATURE - 40°C to +85°C / - 40°F to +185°F
INGRESS PROTECTION (IP) RATING IP 65 (Waterproof)
STANDARD TEST CONDITIONS
(STC) FOR SOLAR MODULE
Irradiance Level: 1000W/m
2
Spectrum: AM1.5
Cell Temperature: 25°C / 77°F
OTHER COMPONENTS / PARAMETERS
CABLE SETS FOR BATTERY Main Cable Set: 14ft cable pre-wired to Charge Controller.
Battery end has 2-Pole, 50A Mating Type Battery Connector
and 10A fuse.
Adapter Set 1: 2-Pole, 50A Mating Type Battery Connector to
Battery Clamps, 2ft
Adapter Set 2: 2-Pole, 50A Mating Type Battery Connector to
SAE Connector, 2ft
DIMENSIONS (Unfolded)
W x H x D
1515 x 620 x 30 mm
59.65 x 24.41 x 1.18 in
1035 x 645 x 30 mm
40.75 x 25.39 x 1.18 in
Weight 16.18 kg / 35.6 lb 11.45 kg / 25.2 lb
Note: Specications are subject to change without notice.
OVERALL SPECIFICATIONS

SamplexPower MSK-90 Specifications

General

Brand	SamplexPower
Model	MSK-90
Category	Solar panel
Language	English
