SamplexPower PST-600-12 - Inverter Physical Dimensions and Mounting

38 | SAMLEX AMERICA INC.
SECTION 8 | Installation
8.3 OVERALL DIMENSIONS
Overall dimensions and location of mounting slots are shown in Fig. 8.1 below:
Fig. 8.1 PST-600 Overall Dimensions & Mounting Slots
NOTE: Dimensions are in mm
PST-600-dimensions
200 14.0 5.0
14.0
5.0
32
12
162
32
12
1.6
9.5
5
276.2
NEG –
WARNING:
Reverse polarity will damage the unit.
AVERTISSEMENT :
Inversion de polarité peut endommager l’unité.
NEG – POS +
238
82
