Sams AA-20 - Installation of Aa-20; INSTALLATION of AA-20 P

AA
Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs
elektronik
13
Distribution ampliers
1
2
3
GAIN
1x20 balanced analog audio distribution amplifier with transformer coupled input
AA-20pt
www.sams.rs
POWER
+
–
OUTPUT131211 14 15 16 17 19 2018
+
–
OUTPUT321 4 5 6 7 9 108
FUSE: 500mA
AC ~230V/50Hz
INPUT
GAIN
11-20
GAIN
1-10
www.sams.rs
Made in Serbia
AA-20pt
SN:
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
RIZIK OD STRUJNOG UDARA
NE OTVARATI
UPOZORENJE
USE ONLY WITH A 250V FUSE
Turn on the device
by pressing the switch.
Connect the power cord.
The device works only on AC ~ 230 V / 50 Hz.
Connect all necessary connectors
before the unit is turned on.
Setting the output level
LEDs to indicate the presence of power
+ V: red LED
- V: green LED
Audio outputs
Audio input
1x20 balanced analog audio distribution amplifier
Power 1-10
AA-20
www.sams.rs
+
–
Power 11-20
+
–
1
2
GAIN
FUSE: 500mA
AC ~230V/50Hz
INPUT
GAIN
11-20
GAIN
1-10
www.sams.rs
Made in Serbia
AA-20
SN:
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
RIZIK OD STRUJNOG UDARA
NE OTVARATI
UPOZORENJE
OUTPUT131211 14 15 16 17 19 2018
OUTPUT321 4 5 6 7 9 108
USE ONLY WITH A 250V FUSE
Connect the power cord.
The device works only on AC ~ 230 V / 50 Hz.
Connect all necessary connectors
before the unit is turned on.
Setting the output level
Audio outputs
Audio input
LEDs to indicate the presence of power
+ V: red LED
- V: green LED
INSTALLATION OF AA-20p
INSTALLATION OF AA-20
