Distribution ampliers
Audio distribution is factory set to 0dB input / 0dB output. For adjust is used 1m cable.
To adjust the distribution in the system, it is necessary to have:
- Signal generator (a signal which is brought to the input of the distribution)
- Adequate measuring instrument (output signal of the distribution)
- A small flathead screwdriver (for adjusting)
Put a thin screwdriver through an opening in the
panel.
It can be adjusted by turning the trimmer.
ACCESS TO ADJUST TRIMMER
ADJUSTMENT
NOTES
