1
2
GAIN
FUSE: 500mA
AC ~230V/50Hz
POWER
ON
INPUT
GAIN 1-10
GAIN 11-20
www.sams.rs
Made in Serbia
AA-20wt
CODE: 007.256
SN:
ELECTRICAL SHOCK HAZARD
DO NOT OPEN
CAUTION
RIZIK OD STRUJNOG UDARA
NE OTVARATI
DOK JE POD NAPONOM
UPOZORENJE
USE ONLY WITH A 250V FUSE
1x20 balanced analog audio
distribution amplifier with
transformer coupled input
www.sams.rs
OUTPUT 1-10321 4 5 6 7 9 108
+
–
OUTPUT 11-20131211 14 15 16 17 19 2018
+
–
AA-20wt
3
Turn on the device
by pressing the switch.
Connect the power cord.
The device works only on AC ~ 230 V / 50 Hz.
Connect all necessary connectors
before the unit is turned on.
Setting the output level
LEDs to indicate the presence of power
+ V: red LED
- V: green LED
Audio outputs
Audio input
To Next Page
