Samson 3251 - Page 42

5-6 EB 8052 EN
Installation
3
83
82
82
310
310
92
84
85
255
Legend
3 Yoke
82 Screws
83 Hanger
84 Travel indicator scale
85 Screws
92 Castellated nut
255 Warning label
310 Ball bearing
Plug stem
Fig.5-2: Overview of yoke assembly with travel indicator scale in the standard version
