EB 8111/8112 EN 19
Design and principle of operation
Dimensions and weights
The dimensions and weights for the DIN ver-
sions are listed in Table2.
The dimensions and weights for the ANSI
versions are listed in Table3.
Refer to the following data sheets for more
dimensions and weights:
uT8313 for Type3372 Electropneumatic
Actuator
uT8317 for Type3371 Pneumatic Actuator
uT5824 fore Type5824/5825 Electric Ac-
tuator
uT8331 for Type3374 Electric Actuator
Note
