Owners Manual10
2. Microphone - Micro-miniature, 3mm omni-directional microphone capsule.
3. USB DC Power Input - Connect the supplied universal adaptor to recharge the internal Lithium Ion battery. The USB DC input
will also accept USB bus power from a computer USB port, or any 5-volt DC adaptor that has a USB output.
NOTE: The Universal AC Adaptor will charge the AH2 & AR2 faster than a computer USB port.
NOTE: The USB port is only used for charging purposes and cannot be used for data exchange between a PC and the AH2
transmitter.
1. Status Indicator - This LED displays the operation mode,
low battery and recharge status of the transmitter.
Guided Tour - AH2 Transmitter
GREEN Normal Operation
Flashing GREEN Mute
Flashing YELLOW Volume Adjustment Mode
Fastest Flashing YELLOW Maximum Level
Slowest Flashing YELLOW Minimum Level
Flashing BLUE Low Battery
BLUE Recharging - LED will turn o
when AH2 is fully charged
