AirLine Micro Earset 15
1. Status Indicator - This LED displays the operation mode,
low battery and recharge status of the transmitter.
GREEN Normal Operation
Flashing GREEN Mute
Flashing YELLOW Volume Adjustment Mode
Fastest Flashing YELLOW Maximum Level
Slowest Flashing YELLOW Minimum Level
Flashing BLUE Low Battery
BLUE Recharging (LED will turn
off when fully charged)
Guided Tour - AH2 Transmitter
1
4
3
2
2. Microphone - Micro-miniature, 3mm omni-directional microphone capsule.
3. USB DC Power Input - Connect the supplied universal adaptor to recharge the internal Lithium Ion battery. The USB DC
input will also accept USB bus power from a computer USB port, or any 5V DC adaptor that has a USB output.
NOTE: The Universal AC Adaptor will charge the AH2 & AR2 faster than a computer USB port.
NOTE: The USB port is only used for charging purposes and can’t be used for data exchange between a PC and the AH2.
