Samson Resolv 65a RESOLV65A RESOLV65A User Manual

3
ENGLISH
RESOLV 65a Features
The Samson RESOLV 65a reference monitors provide a smooth response that is accurate, and at the same time pleasant
to listen to. Here are some of its main features:
• Two-way, active studio reference monitor with ported tuned enclosure providing extremely accurate
monitoring for recording studio, post-production and multi-media applications.
• 16.5 cm Copolymer Butyl Surround woofer provides tight and controlled low frequency response.
• 2.5 cm Titanium Dome tweeter with Neodymium magnet, plus Heat-sink and Ferro-Fluid
Cooling provides smooth and sweet high frequency response.
• Bi-Amp Power with 75 watts on the LF driver and 25 watts on the HF driver.
• Four-position midrange Presence control allows the user to contour the response curve to emulate
monitors from hi-fi, through flat and all the way to aggressive midrange nearfield.
• Active crossover utilizing a multi-pole design for linear response from bottom to top.
• XLR and 1/4-inch balanced inputs, as well as unbalanced RCA inputs make connecting to most any -10
or + 4db signal source quick and easy.
• A/V shielded for multimedia applications providing clean operation near computer monitors.
• Solid MDF (Medium Density Fiberboard) construction, extremely rigid delivering maximum SPL.
• Black satin finish is attractive and durable thanks to the heavy textured epoxy paint.
• Three-year extended warranty.
®
