ENGLISH
1 MID RANGE CONTOUR CONTROL
position switch used to adjust the midrange
response (in 3dB increments) providing custom-
ized voicing from hi-fi, to aggressive mid-range,
- Controls the amount of output level.
- Balanced, line level input is con-
nected here via standard XLR (microphone)
– Used to connect signals from unbalanced,
– Balance TRS (Tip, Ring,
Sleeve) 1/4-inch phone plug used to connect
balanced or unbalanced line level signals.
– Main power switch. When
set to the on position, illuminates green indicat-
ing the Resolv 65a is powered up and ready for
- Connect the supplied IEC power
