- BN94-00350A ASSY PCB MAIN GH19BS SNA
C373 2409-001043 C-ORGANIC 47UF,20%,6.3V,WT,TP,6.3X6.8,2.5
C622 2409-001043 C-ORGANIC 47UF,20%,6.3V,WT,TP,6.3X6.8,2.5
CIS 0201-001223 ADHESIVE-TS HT-130S,RED,700+/- 50,- SNA
CIS 0202-001044 SOLDER-WIRE. S63S-W3.0,S63S,D3,63Sn/37Pb,- SNA
CIS 0202-001046 SOLDER-WIRE FLUX CF-110VH-2A,-,-,-,- SNA
CIS 0202-001162 SOLDER-CREAM RMA-20-21L,S63,-,SN63/PB36.6/AG0.4,FLUX9.5% SNA
CIS 0202-001222 SOLDER-WIRE FLUX RS-107,RS60-1.2AA,D1.2,SN60/PB40,- SNA
CIS 0204-001095 THINNER #4520,-,-,- SNA
CIS 6011-001445 BOLT-SOCKET 4-40 UNC,L7,NI PLT,BRASS,HEX SOCKET SNA
CIS BN39-00162A CBF HARNESS
GH17LS,UL/CSA,UL1061#28,12P/12P,240MM,WHT,UL1061#28,51021-1200,51021-1200,BK,300
CIS BN39-00207B LEAD CONNECTOR-ASSY
GH17BS,UL1617#22,UL/CSA,3(2)P,#22,JRA-1102H(S/W),YH396-03V,BK,85MM,1617#22,SJ02-
CIS BN39-00241B LEAD CONNECTOR
GH17BS,UL1571#30,UL/CSA,30P,#30,12507HS-30,FI-X30H,BK,210MM,1571#30,SJ02-01-116,
CIS BN44-00041A INVERTER
ML17,SIC1803,48KHz,14VDC,1.5mArms,7.2mArms,48Khz,160*45*17,4LAMP,48Khz,-,-
CIS BN44-00055B ADAPTOR
DP46L,GH18 DELL,90~264,12.5V/5.0V,2.5A/2A,42W,0 TO +40 C,INLET SOKET NORMAL
CIS BN61-00161A GUIDE-POWER GH17PS,ABS PC,-
CIS BN63-00303A SHIELD-POWER GH17PS,SECC,T0.5
CIS BN63-00308A SHIELD-D_SUB GH19PS,SPTE,T0.5
CIS BN70-00269A PLATE GH19PS,PBC,-,T0.15,-,-,-,-,- SNA
CIS BN71-00024A EARTH PLATE GH17LS,SUS,T0.15 SNA
CN201 3701-001219 CONNECTOR-DSUB 15P,3R,FEMALE,ANGLE,AUF
CN202 3701-001173 CONNECTOR-DSUB 24P,3R,FEMALE,ANGLE,AUF
IN/PCB+SH/COV 6003-000264 SCREW-TAPTITE PWH,+,B,M3,L6,ZPC(YEL),SWRCH18 SNA
SH/PCB+M/PCB 6003-000264 SCREW-TAPTITE PWH,+,B,M3,L6,ZPC(YEL),SWRCH18 SNA
SH/PCB+SH/D_SUB
6003-000117 SCREW-TAPTITE BH,+,B,M3,L6,ZPC(YEL),SWRCH18A SNA
SH/PCB+SH/POW
6003-000117 SCREW-TAPTITE BH,+,B,M3,L6,ZPC(YEL),SWRCH18A SNA
SH/PCB+SMPS 6003-000264 SCREW-TAPTITE PWH,+,B,M3,L6,ZPC(YEL),SWRCH18 SNA
CIS BN96-00141A ASSY MISC P-SHIELD GH19BS,SECC T1.0
CIS BN96-00142A ASSY MISC P-SHIELD D/SUB GH19BS,SPTE T0.2
- BN97-00140A ASSY SMD GH19BS SNA
C110 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C112 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm
C135 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C204 2203-000626 C-CERAMIC,CHIP 0.022nF,5%,50V,NP0,TP,1608
C214 2203-000236 C-CERAMIC,CHIP 0.1nF,5%,50V,NP0,TP,1608
C215 2203-000236 C-CERAMIC,CHIP 0.1nF,5%,50V,NP0,TP,1608
C252 2203-000236 C-CERAMIC,CHIP 0.1nF,5%,50V,NP0,TP,1608
C301 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C302 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C303 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C304 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C305 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C306 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C307 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C308 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C309 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C310 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C311 2203-001607 C-CERAMIC,CHIP 0.22nF,5%,50V,NP0,TP,1608
C312 2203-001607 C-CERAMIC,CHIP 0.22nF,5%,50V,NP0,TP,1608
C313 2203-001607 C-CERAMIC,CHIP 0.22nF,5%,50V,NP0,TP,1608
C314 2203-001607 C-CERAMIC,CHIP 0.22nF,5%,50V,NP0,TP,1608
C315 2203-001607 C-CERAMIC,CHIP 0.22nF,5%,50V,NP0,TP,1608
GH19B* 6-1
Loc. No. Code No. Description Specification Remarks
CONFIDENTIAL
6 Electrical Parts List
6-1 Main PCB Parts
