6 Electrical Parts List
6-2
Level Loc. No. Code No. Description & Specification EA SA/SNA
0.1 M0112 BN91-01001W ASSY SHIELD;DP21WS 1 S.N.A
..2 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 3 S.N.A
..2 BN63-02474A SHIELD-LAMP;LS215TW,SPTE,T0.3 1 S.N.A
..2 T0279 BN63-02475B COVER-JACK;LS215TW,HIPS,T2.0,V0,BK24 1 S.N.A
0.1 M0017 BN91-01021F ASSY CHASSIS-SPZ,W/W;LS21DPW*,W/W 1 S.A
..2 M0081 6003-001439 SCREW-TAPTITE;BH,+,S,M4,L8,ZPC(YEL) 1 S.N.A
..2 T0376 BN63-02473A SHIELD-VIDEO;LS215TW,SPTE,T0.3 1 S.N.A
..2 M0146 BN63-02505A SHIELD-PCB SMPS;LS215TW,SPTE,T0.3 1 S.N.A
..2 M0014 BN94-00846P ASSY PCB MAIN-SPZ,W/W;LS21DPW* 1 S.A
...3 T0245 0202-001522 SOLDER-WIRE FLUX;LFA3-107,-,D1.2,96.5Sn/ 0.025 S.N.A
...3 CN102 3701-001173 CONNECTOR-DVI;24P,3R,FEMALE,ANGLE,AUF 1 S.A
...3 CN101 3701-001219 CONNECTOR-DSUB;15P,3R,FEMALE,ANGLE,AUF 1 S.A
...3 CN604 3722-001782 JACK-PIN;1P,SN,WHT,ANGLE 1 S.A
...3 CN605 3722-001784 JACK-PIN;1P,SN,RED,ANGLE 1 S.A
...3 CN603 3722-002081 JACK-EAR PHONE;5P/2C,-,SnPb,L-BLU,- 1 S.A
...3 CN103 3722-002267 JACK-PIN;3P,AU,RED/WHT/YEL,ANGLE 1 S.A
...3 CN104 3722-002275 JACK-DIN;4P,-,SN,BLK,- 1 S.A
...3 CN705 3722-002389 JACK-PIN;3P,AU,RED/BLU/GRN,ANGLE 1 S.A
...3 HDCP KEY BN97-00707A ASSY HDCP;BN46-00018A,BR20/21BS_CS,MSTAR 1 S.N.A
....4 BN46-00018A KEY CODE-CERTIFICATE;(HDCP KEY)PPM42M5S, 1 S.N.A
...3 T0174 BN97-00832A ASSY SMD;LS21DPWAB/XAA 1 S.N.A
....4 CIS5 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45?,96.5Sn/3 2.572 S.N.A
....4 D101 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D102 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D103 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D104 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D105 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D106 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D107 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D108 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D109 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D110 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D111 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D113 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D114 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D117 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D118 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D119 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D712 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D713 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D501 0402-000553 DIODE-RECTIFIER;SS24,40V,2A,DO-214AA,TP 1 S.A
....4 D502 0402-000553 DIODE-RECTIFIER;SS24,40V,2A,DO-214AA,TP 1 S.A
....4 D503 0402-000553 DIODE-RECTIFIER;SS24,40V,2A,DO-214AA,TP 1 S.A
....4 ZD106 0402-000553 DIODE-RECTIFIER;SS24,40V,2A,DO-214AA,TP 1 S.A
....4 D115 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD102 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD103 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD104 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD105 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 D606 0403-001016 DIODE-ZENER;RLZ6.2B,5.96-6.27V,500mW,LL- 1 S.A
....4 ZD401 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 ZD731 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 ZD732 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 ZD502 0403-001411 DIODE-ZENER;-,5.49-5.73V,200mW,SOD-323,T 1 S.A
....4 ZD101 0403-001435 DIODE-ZENER;QZX363C5V6,5.32-5.88V,200MW, 1 S.A
To Next Page
