6 Electrical Parts List
6-3
....4 ZD107 0403-001435 DIODE-ZENER;QZX363C5V6,5.32-5.88V,200MW, 1 S.A
....4 ZD501 0406-001061 DIODE-TVS;MMQA5V6T3,5.32/5.6/5.88V,24W,S 1 S.A
....4 D120 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 D121 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 D122 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 D123 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 D602 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 D603 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 D604 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 D605 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 ZD109 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 ZD733 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 Q506 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q101 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q102 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q501 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q502 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q503 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q504 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q602 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q603 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q604 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q605 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q607 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q608 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q609 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q409 0505-001170 FET-SILICON;SI9933ADY-T1,P,-20V,3.4A,0.0 1 S.A
....4 IC104 0801-002267 IC-CMOS LOGIC;74LCX14,-,SOIC,14P,150MIL, 1 S.A
....4 IC104 0801-002404 IC-CMOS LOGIC;74VHC4066,ANALOG SWITCH,SO 1 S.A
....4 IC104 0801-002404 IC-CMOS LOGIC;74VHC4066,ANALOG SWITCH,SO 1 S.A
....4 IC104 0801-002404 IC-CMOS LOGIC;74VHC4066,ANALOG SWITCH,SO 1 S.A
....4 IC104 0801-002478 IC-CMOS LOGIC;7SZ14,SCHMITT TRIGGER,SOT2 1 S.A
....4 IC104 0801-002709 IC-CMOS LOGIC;74HC373,D FLIP-FLOP,TSSOP, 1 S.A
....4 IC520 0903-001423 IC-MICROCONTROLLER;WT6600F,-,QFP,128P,20 1 S.A
....4 IC108 1002-001398 IC-A/D CONVERTER;MST9883CR-110,24Bit(8x3 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-001314 IC-EEPROM;24C16,2Kx8,SOP,8P,5x4mm,2.7/5. 1 S.A
....4 IC202 1105-001538 IC-VIDEO RAM;K4D263238,-,128M,4x1Mx32Bit 1 S.N.A
....4 T0085 1201-002271 IC-AUDIO AMP;APA2068,SOP,16P,150MIL,DUAL 1 S.A
....4 IC508 1202-000164 IC-VOLTAGE COMP.;393,SOP,8P,150MIL,DUAL, 1 S.A
....4 IC304 1203-001559 IC-RESET;DS1834A,SOIC,8P,150MIL,PLASTIC, 1 S.A
....4 T0087 1203-002351 IC-POSI.FIXED REG.;LF25C,DPAK,3P,240MIL, 1 S.A
....4 T0087 1203-002351 IC-POSI.FIXED REG.;LF25C,DPAK,3P,240MIL, 1 S.A
....4 T0087 1203-002351 IC-POSI.FIXED REG.;LF25C,DPAK,3P,240MIL, 1 S.A
....4 IC502 1203-002796 IC-DC/DC CONVERTER;AP1501-33K5A,TO-263-5 1 S.A
....4 IC501 1203-002843 IC-DC/DC CONVERTER;AP1501-50K5A,TO-263-5 1 S.A
....4 IC504 1203-002889 IC-DC/DC CONVERTER;AP1501-K5A,TO263-5L,5 1 S.A
....4 T0087 1203-003704 IC-POSI.FIXED REG.;G953-18T6U,SOT-223,3P 1 S.A
....4 IC402 1204-002419 IC-VIDEO DECODER;TW9906,TQFP,80P,12x12mm 1 S.A
....4 IC109 1205-002823 IC-LCD CONTROLLER;MST6281LA-LF-165-1,LQF 1 S.A
....4 R237 2007-000040 R-CHIP;150ohm,1%,1/10W,TP,1608 1 S.A
....4 R307 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
....4 R536 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R537 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 JP601 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R108 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
Level Loc. No. Code No. Description & Specification EA SA/SNA
