Place a soft cloth over the table to protect the TV, and then
place the TV on the cloth screen side down.
✎
Insert the Stand Guide into the slot of TV bottom side.
1 2
B
A
C
(M4 X L12)
x4
Top View
DO NOT USE
CHEMICALS
DO NOT USE
GREASE
DO NOT USE
OIL
ATTENTION
Rear
Front
C
(M4 X L12)
x4
✎ Make sure to distinguish between the front and back of the Stand and Stand Guide when assembling them.
✎ Make sure that at least two people lift and move the TV.
(Correct assembly)
Side View
3
(Incorrect assembly)
