3. Cable routing
LCD Cable
SPK CABLE-
USB FPC
Battery Cable
KBD Membrane
WLAN Cable
SPK CABLE-R
KBD Backlight Cable
Fan Cable
Fingerprint FPC
SSD Slot1
T/P FFC
