10. (1) Remove the screws on Bracket main port.
(2) Remove the screws on Front.
(3) Remove the screws on Main board.
(4) Remove Bracket main port and Main board.
1. Main System
Common
SCREW-MACHIN
(6001-001650) 7 PCS
Torque : 2.3 ~ 2.7Kgfcm
Assembly order is reverse of disassembly
