Mobile communications Division
- 6 -
1. Main System
7. Connector cable disassemble point
LCD Cable
KBD Membrane
SPEAKER -L
TP FFC
SPEAKER -R
KBD Backlight
FPC
FINGER PRINT
FFC
Antenna Cable
FAN CABLE
MAIN TO SUB
FPC
Power board
FFC
