Samsung AC MN KH/EU Series Service Manual

5-6 Samsung Electronics
①
#1-#3 : AC220V
②
#1~#28 : SIGNAL TO SUB PCB
③
#1~#2 : OLP THERMISTOR
④
#1 : DC12V
#2 : RXD
#3 : TXD
#4 : GND
⑤
#1~#5 : EEV SIGNAL
#6 : DC12V
⑥
#1 : COM1(F1)
#2 : COM2(F2)
⑦
#1~#2 : OUTDOOR THERMISTOR
#3~#4 : DISCHARGE THERMISTOR
#5~#6 : COND THERMISTOR
⑧
#1~#10 : Download
⑨
#1: DV310V
#3: GND
#4: DC15V
#5: FAN_PWM
#6: FAN_Feedback
⑩
#1~#10 : Download
⑪
#1 : COMP U-Phase
#2 : COMP V-Phase
#3 : COMP W-Phase
⑫
#1~#2 : Reactor
CN030 : 4WAY VALVE CN951 : SIGNAL TO SUB PCB CN252 : THERMISTOR CN851:S-NET Communication
CN701 : EEV
CN901 : BLDC MOTOR
CN302:Communication(COM1)
CN551: Downloader
CN251 : THERMISTOR
CN451 : COMP POWER
CN201 : Downloader
CN051 : Reactor
