Samsung Electronics 5-3
No Part Code Local Function Description
14 3711-000795 CN804 SMW250-02(BLU) FAN MOTOR COMM
15 3711-004182 CN905 SMW200-10(WHT) EVA DIS/OUT SENSOR
16 3711-003895 CN501 SMW200-13(WHT) 2WIRE OPTION
17 3711-000794 CN411 SMW250-02(BLK) LOUVER
18 3711-000015 CN412 SMW250-02(WHT) ROOM-TEMP
19 3711-004236 CN413 SMW200-06(NTR) EEPROM PBA
20 3711-004236 CN413 EVA DIS/OUT SENSOR
SMW200-06P WHT
#1 - EVA IN SIGNAL
#3 - EVA OUT SIGNAL
#5 - DISCHARGE SIGNAL
#2,4,6 - GND
#1 - L, #3 - N
