Disassembly and Reassembly
42 Samsung Electronics
No Parts Procedure Remark
8 FAN 1) Turn the one nut as shown in the picture and
remove it.
(Use adjustable wrench)
9 MOTOR 1) Remove the fan.
2) Unscrew and remove the four motor screws.
(Use '+' type screw driver)
3) Disconnect the motor wire from the
Ass'y Control Out.
To Next Page
