Disassembly and Reassembly
Samsung Electronics 45
No Parts Procedure Remark
12 ASSY 4WAY VALVE 1) Purge the coolant first.
2) Unscrew and remove the four screws
on the SERVICE VALVE.
(Use '+' type screw driver)
3) Separate the pipe from the Entrance/Exit
using a welder.
When removing the compressor,
heat exchanger and pipe, purge the
completely and remove the pipe
with a welding flame.
To Next Page
