Troubleshooting
382 Samsung Electronics
1. Inspection Method
4-4-58 Sump Sensor Error Due to Protection Control
No
Is the sensor connector
properly connected to PCB?
Is the sensor displaying
the temperature normally?
Is the sensor properly attached to
the sensor holder below the compressor?
Refer to the solution method for the
liquid-compression prevention error (E477).
Re-connect and check the connector.
Yes
Yes
Yes
No
No
Re-attach and check sensor.
Check by referring to the other temperature
sensor problem check-up methods.
Outdoor unit display
Indoor unit display
×(Operation) (Reservation) (Blast) (Filter) ×(Defrost)
Criteria
• Maintain sump temperature of 95°C or more for five minutes
Cause of problem
• Compressor loading faulty/sump temperature sensor faulty

Samsung AM017HN1DEH/EU Specifications

General

Type	Air conditioner indoor unit
Cord length	2.5 m
Multi-split	-
Product color	White
Gas hose diameter	12.7 mm
Liquid hose diameter	6.35 mm
Refrigerating medium	R410A
Air conditioner functions	Cooling, Heating
Cooling capacity (nominal)	5800 BTU/h
Heating capacity (nominal)	6500 BTU/h
Heating capacity in watts (max)	1900 W
Cooling capacity in watts (nominal)	1700 W
Heating capacity in watts (nominal) (Warmer heating season)	- W
AC input voltage	220-240 V
Current (cooling)	0.14 A
AC input frequency	50 Hz
Design load (cooling)	- kW
Power consumption (cooling) (max)	24 W
Hourly energy consumption (cooling)	- kWh
Indoor unit type	Ceiling
Indoor unit depth	135 mm
Indoor unit width	740 mm
Indoor unit height	360 mm
Indoor unit weight	8000 g
Indoor units quantity	1
Indoor unit package depth	435 mm
Indoor unit package width	895 mm
Indoor unit package height	223 mm
Indoor unit package weight	10800 g
Cooling airflow (indoor unit)	4.3 m³/h
Indoor unit sound power level	46 dB
Indoor unit noise level (low speed)	21 dB
Indoor unit noise level (high speed)	27 dB
Outdoor unit noise level	- dB
