Exploded Views and Parts List
■
Parts List
1 DB98-21999D ASS'Y-CABINET UNIT HP-S182P,SUPREME-PJT 1 1 SNA
1-1 DB63-00333A COVER-CAP CABINET L-P/J,HIPS,T2,-,-,-,-, 1 1 SA
2 DB94-00519B ASS'Y-DIE BOTTOM APH289SEF/XFO,SUPREME-PJ 1 1 SNA
2-1 DB64-00579E DECO DIE-BOTTOM HP-S182P,HIPS,T3.0,358.9 1 1 SA
2-2 DB61-01041B BRACKET-TERMINAL KFRD-70LW/SSA,SGCC-M,T1 1 1 SNA
2-3 2301-001380 C-FILM,LEAD-OTHER 4500nF,+10-5%,450V,BK, 1 1 SA
3 DB63-00519A COVER-TERMINAL AP-SR2370,ABS(V0),-,-,-,- 1 1 SC
4 DB31-00161C MOTOR FAN-OSME 618SAC OSM 618SAC,-,-,50, 1 1 SA
4-1 DB73-00078A GROMMET-MOTOR IN -,NBR,-,-,-,-,-,BLK,C1- 3 3 SA
5 DB67-00288A BLOWER AP-SR2370,ABS+GF10%,324,1,3.5, 1 1 SA
6 DB60-30027A SCREW-MACHINE HEX,2C,M12,ZPC3,SCP1,- 1 1 SA
7 DB90-01343A ASS'Y-DUCT CASE HP-S2371,SUPREME P/J 1 1 SA
7-1 DB67-00242A DUCT-CASE AP-SR2370,HIPS,-,-,-,GREY,SUPR 1 1 SA
7-2 DB63-00520A COVER-GAS SENSOR AP-SR2370,HIPS,-,-,-,-, 1 1 SNA
7-3 DB93-00368B ASS'Y PCB-GAS SENSOR SP3S-AQ2,LEAD FREE 1 1 SA
8 DB94-00477B ASS'Y-PANEL DRAIN HP-S2371,ABS 1 1 SA
8-1 DB64-00580A PANEL-DRAIN AP-SR2370,ABS,-,-,-,-,GREEN, 1 1 SC
8-2 DB94-00315P ASS'Y-HOSE DRAIN HP-SR2371GB,SUPREME-PJT 1 1 SA
9 DB90-01344A ASS'Y-BELL MOUTH HP-S2371,SUPREME P/J 1 1 SA
10 DB90-01414B ASS'Y COVER-TOP HP-S182P,Supreme 1 1 SA
10-1 DB63-00544D COVER-TOP HP-S182P,HIPS,T2.5,209.2,523,- 1 1 SNA
10-2 DB94-00244A ASS'Y-COVER TOP INNER AP-SR2370,SUPREME-P 1 1 SA
11 DB63-00523A COVER-EVAP RH AP-SR2370,HIPS,-,-,-,-,-,G 1 1 SA
12 DB63-00524A COVER EVAP-LF AP-SR2370,HIPS,-,-,-,-,-,G 1 1 SA
13 DB96-04683C ASS'Y EVAP-PARTS APH289SEF/XFO,SUPREME-PJ 1 1 SNA
14 DB98-22262G ASS'Y-SHUTTER HP,KFRD-70L/SSF,6uF,-,-,720 1 - SA
DB98-22262F ASS'Y-SHUTTER
SATIN SILVER,HP,KFRD-70L/SSF,6uF,-,-,720
-1SA
15 DB98-21625A ASS'Y-INLET HP,HP-S182P,-,-,-,-,-,-,-,-,- 1 1 SNA
16 DB94-00517A ASS'Y-PERFECT CLEANER APH289SE,CIS TYPE 1 1 SNA
17 DB98-21626E ASS'Y-PANEL DISPLAY CO,SUPREME-PJT,-,-,-, 1 1 SNA
Code No. Description SA/SNANo.
Q'TY
APH289SEF APH289SEG
Specification
To Next Page
