Exploded Views and Parts List
■
Parts List
1 DB90-00565C ASS'Y CABINET FRONT APH-H2320, 1 SA
2 DB90-20157K ASS'Y BASE OUT AP-7550,SC-90073T 1 SNA
3 DB67-00140A PROPELLER-FAN OUT AS+GF 20%,BLK,OD460,B- 1 SA
4 DB60-20021J BOLT-WELD -,M8,L39,-,-,- 4 SNA
5 DB31-00136B MOTOR FAN 0SME-1056SRC(S,F2K-PJT,-,-,-,- 1 SA
6 DB90-00967A ASS'Y-BRACKET MOTOR APH-H2320,H-P/J 1 SA
7 DB94-00359C ASS'Y PARTITION APH289SE,CIS 1 SNA
8 DB98-23550A ASS'Y-COND UNIT APH289SEN/XFO,SUPREME-PJT 1 SNA
9 DB90-40176A ASS'Y COVER-CONTROL C-PROJECT,HIPS,INSU 1 SA
10 DB90-00568E ASS'Y CABINET-SIDE RH APH289SE,CIS TYPE 1 SA
11 DB90-00569A ASS'Y CABINET-UPPER AP-L23✳✳,- 1 SA
12 DB95-10243B ASS'Y COMP APH-701H,ZR34K3-PFJ 1 SA
13 DB60-30028A SCREW-MACHINE HEX,2C,M8,ZPC,-,- 4 SA
14 DB73-10023A GROMMET-COMP -,EPDM,T41,-,-,-,-,BLK,- 4 SNA
15 DB93-02606A ASS'Y CONTROL-BOX OUT HP,-,-,-,-,-,-,-,-, 1 SA
15-1 DB34-90057C SWITCH-MAGNET 45CG20ALB,-,-,-,220/240V20 1 SA
15-2 2301-001369 C-FILM,LEAD-OTHER 3000nF,+10-5%,450V,BK, 1 SA
2501-001240 C-OIL 50uF,450V,BK,53x125mm,20.6 1 SA
15-3 DB65-40062Q TERMINAL BLOCK APH289SE,7P,12345NL,300V, 1 SA
15-4 DB95-90026B ASS'Y-SPARK KILLER PAC,- 1 SA
16 DB63-00369B FILTER-COMP SOUND APH289SE,PVC SHEET &GR 1 SNA
17 DB96-03125A ASS'Y TUBE-CHECK VALVE APH289SE,CIS TYPE 1 SNA
18 DB96-03043A ASS'Y TUBE-4WAY VALVE APC503QF,CIS TYPE 1 SNA
