51Samsung Electronics
PCB Diagram
F101 FUSE-CARTRIDGE 250V,F1A,FUSE 1
F701 FUSE-CARTRIDGE 250V,3.15A,TIME-LAG,GLASS,5x20mm 1
F701,F101 HOLDER FUSE FB58-20 2
VA701 VARISTOR INR14D561K-RS,560V,2500A,17.5x7.5mm,TP 1
C305 RC-NETWORK RC-NETWORK(2.2nF+12Mohm) 1
C501 C-FILM,MPPF 1.2uF,10%,450Vac,BK,38x18x30,3 1
C301 C-AL 22uF,20%,450V,LZ,BK,16x25mm,7.5 1
C701,705 C-FILM,PCF 220nF,10%,275V,BK,18X12X6,15 2
C706 C-FILM,MPPF 0.14ßfi,10%,600VAC,BK,25.6x15.0 1
U303 IC-POSI.FIXED REG. KA7805,TO-220,3P,-,PLASTIC,4.8/5 1
U303 HEAT SINK A6063,L25.5 W15,WHT 1
U303 SCREW-TAPPING PH,M3,L8,FE FZY 1
L701 NOISE-FILTER LS404190M,AS-S660,19mH,+50,-30%,-,300Mohm,2A 1
U501 SSR G3MB202PL,12Vdc,-,2A,1mS,1mS 1
RY702~RY710 RELAY-POWER US11-12S1, DC12V,3A 9
T301 TRANS SWITCHING S-PJT,AP-S2370,-,220V,-,-,EE2216 1
CN101 CONNECTOR-HEADER SMW200-03, YEL 1
CN201 CONNECTOR-HEADER SMW200-06, YEL 1
CN202 CONNECTOR-HEADER SMW200-06, WHT 1
CN203 CONNECTOR-HEADER SMW200-05, WHT 1
CN204 CONNECTOR-HEADER SMW200-06, RED 1
CN401 CONNECTOR-HEADER SMW200-06, BLU 1
CN403 CONNECTOR-HEADER SMW200-03, WHT 1
CN501 CONNECTOR-HEADER YW396-05AV, WHT 1
CN502 CONNECTOR-HEADER SMW250-03, BLU 1
CN701 CONNECTOR-HEADER YW396-05AV, BLU 1
CN702 CONNECTOR-HEADER YW396-03AV, BLU 1
CN703 CONNECTOR-HEADER YWL500-05, WHT 1
CN704 CONNECTOR-HEADER YW396-05AV, YEL 1
CN707 CONNECTOR-HEADER SMW200-04, WHT 1
CN710 CONNECTOR-HEADER SMW200-03, RED 1
CN901 CONNECTOR-HEADER SMW200-05, RED 1
DB41-00246A PCB BOARD FR-1, W250xH197.5, 1x2, (20617A) 1
DB93-02594D CODE LABEL STICKER 30mmx15mm 1
Specification Q'TYDescriptionLocation No.
■
Parts List(cont.)
To Next Page
