Samsung AQ18VBA User Manual

Samsung Electronics 5-4
Exploded Views and Parts List
 Parts List
No. Code No. Description Specification
Q’TY
SA/SNA
AQV18V*AX AQV24V*AX
1 DB90-01146D ASS’Y CABI FRONT ASS’Y, SC-94445T 1 1 SA
2 DB63-00838A GUARD FAN HIPS, SC-90073R
1 1 SA
3
DB90-00970T
ASS’Y BASE OUT ASS’Y, SC-94445T
1 -
SA
DB90-00970K
- 1
4 DB61-01593A BRACKET VALVE SECC-P, SC-94445T
1 1 SA
5 DB67-00142A FAN-PROPELLER AS+G/F20%, Φ420
1 1 SA
6 DB60-30020A NUT-HEXAGON M6
1 1 SA
7 DB31-00264D MOTOR FAN OUT AC Motor
1 1 SA
8 DB61-00686A BRACKET MOTOR SGCC-M
1 1 SA
9 DB94-01210A ASS’Y PARTITION ASS’Y, SGCC-M
1 1 SA
10 DB27-00043A REACTOR PPS, 20A
1 1 SA
11 DB96-04087B ASS’Y COND UNIT ASS’Y
1 1 SA
12 DB90-10616G ASS’Y CABI UP ASS’Y, SC-94445T
1 1 SA
13 DB63-00692A GUARD COND SECC-P, SC-94445T
1 1 SA
14 DB90-01651B ASS’Y CABINET SIDE RH ASS’Y, SC-94445T
1 1 SA
15 DB90-40176B COVER CONTROL ABS, SC-90073R
1 1 SA
16
DB63-01718A
FELT COMP BASE FELT+PVC Sheet
1 -
SA
DB63-01719A
- 1
17
DB63-01669A
FELT COMP SIDE FELT+PVC Sheet
1 -
SA
DB63-01668A
- 1
18
G4B135LUAEH
COMPRESSOR ROTARY, BLDC
1 -
SNA
G8T260FUAEW
- 1
18-1
DB63-00763A
GROMMET ISOLATOR NR
3 -
SNA
DB63-00815A
- 3
18-2 DB60-30028A SCREW HEX M8
3 3 SNA
18-3 DB63-00817A GASKET EPDM
1 1 SNA
18-4 DB63-00816A COVER TERMINAL PBT (G/F 15%)
1 1 SNA
18-5 6021-001142 SCREW MACHINE M5
1 1 SNA
19
DB99-00851A
ASS’Y VALVE 4WAY ASS’Y
1 1
SA
DB99-00852A
19-1 DB62-02338A 4WAY VALVE R410A, SANHUA
1 1 SNA
19-2 DB33-00002C SOLENOID COIL ASS’Y
1 1 SNA
19-3 DB67-00765A ACCUMULATOR STEEL ACCUM.
1 1 SNA
19-4 DB97-02054A TUBE MUFFLER C1220T-0
1 - SNA
19-5
DB62-02285A
VALVE SERVICE
R410A, SANHUA, 1/2”
1 -
SNA
DB62-02342A R410A, SANHUA, 5/8”
- 1
20 DB96-06744A ASS’Y VALVE EEV
1 1 SA
20-1 DB62-03964A VALVE EXPANSION COIL FUJIKOKI
1 1 SNA
20-2 DB62-02863A VALVE EXPANSION BODY FUJIKOKI
1 1 SNA
20-3 DB62-02283A VALVE SERVICE R410A, SANHUA, 1/4”
1 1 SNA
21 DB61-03167A GUIDE SCREEN P.E.H 100%
1 1 SA
22
DB93-04268D ASS’Y CONTROL OUT ASS’Y
1 - SA
DB93-04268C ASS’Y CONTROL OUT ASS’Y
- 1 SA
23 DB32-00176A THERMISTOR OUT/DIS ASS’Y
1 1 SA
24 DB32-00175A THERMISTOR COND ASS’Y
1 1 SA
25 DB39-01301A CONNECT WIRE COMP ASS’Y
1 1 SA
