Samsung AQ18VBA User Manual

Samsung Electronics 5-8
Exploded Views and Parts List
 Parts List
No. Code No. Description Specification
Q’ty
SA/SNA
AQV18V*AX AQV24V*AX
1
2301-001378 C-FILM,LEAD-OTHER 3.5uF,450V
1 - SA
2301-001379 C-FILM,LEAD-OTHER 4.0uF,450V
- 1 SA
2 DB93-04339A ASSY LEAD WIRE SKYBLU 1 1 SNA
3 DB93-04339B ASSY LEAD WIRE-POWER L BRN 1 1 SNA
4 DB93-04337A ASSY CONNECTOR WIRE 5P,MAIN TO DISPLAY 1 1 SNA
5 DB61-01097A HOLDER-WIRE CLAMP ABS,BLK 2 2 SA
6 DB61-02973A CASE-CONTROL BASE ABS V0,T2.0 1 1 SNA
7 DB61-02974A CASE-CONTROL COVER ABS V0,T2.0 1 1 SNA
8 DB61-02977A PLATE-CONTROL OUT SGCC_M,T0.6 1 1 SNA
9 DB61-02975A CASE-DISPLAY PCB ABS V0,T2.0 1 1 SNA
10 DB62-04566B SEAL-COVER CONTROL FOAM-LEX,T2,WHT
1 1 SNA
11 DB62-04626A HEAT SINK 100mm,185mm,50mmm,AL
1 1 SNA
12 DB65-00181C TERMINAL BLOCK DAF-6P
1 1 SNA
13
DB93-04266D ASSY PCB MAIN-OUT PCB-2L
1 - SA
DB93-04266C ASSY PCB MAIN-OUT PCB-2L
- 1 SA
14
DB93-04267B ASSY PCB SUB-EMI PCB-2L
1 - SA
DB93-04267A ASSY PCB SUB-EMI PCB-2L
- 1 SA
15 DB93-04329A ASSY PCB DISPLAY PCB-1L
1 1 SA
16 DB98-17991A ASSY-INSULATOR MICA MICA
2 2 SNA
17 6002-000630 SCREW-TAPPING PH+,M2,L8
3 3 SNA
18 DB91-00306A ASSY-SCREW MACHINE PH+,M3,L16
3 3 SNA
19 DB91-00307A ASSY-SCREW MACHINE PH+,M4,L16
4 4 SNA
20 6002-000555 SCREW-TAPPING PH+,M4,L25
1 1 SNA
21 6001-001054 SCREW-MACHINE TH+,M4,L10
4 4 SNA
22 6009-001001 SCREW-SPECIAL TH+,M4,L8
1 1 SNA
23 6002-000536 SCREW-TAPPING PH+,M4,L10
2 2 SNA
25 DB61-00206B HOLDER-WIRE SGCC_M,T0.5
1 1 SNA
26 6002-000231 SCREW-TAPPING PH+,M4,L10
1 1 SNA
27 DB65-10088D CABLE-TIE NYLON66
1 1 SNA
28 DB95-01040E ASSY NOISE ABSORBER ASSY
1 1 SNA
