Samsung AQ18VBA - Page 26

Samsung Electronics
4-2 Outdoor Unit
4-7
No Parts Procedure Remark
1 Common Work 1) Loosen 1 fixing screw(CCW) of the Cover-
Control and detach the Cover Control.
2) Loosen fixing screws(CCW) and detach the
Cabinet-Upper.
3) Loosen 1 screw(CCW) fixed to assemble Control
Box with Cabinet-Side RH.
4) Loosen 6 fixing screws(CCW) and detach the
Cabinet-Side RH.
