Samsung Electronics
The red number connecter is not used.
10-2 Outdoor PCB
10-2
Power N COND/OLP Temperature Sensor
Power L DIS/OUT Temperature Sensor
BLDC FAN
EEV Connector
AC FAN Comp. Connector Wire
Communication 485 Reactor Connector Wire
6
7
1
2
3
4
5
9
10
8
9 2 1
10
4
3
7
6
8
5
