Samsung AQ18VBA User Manual

Samsung Electronics6-21
Electrical Parts List
 OUTDOOR DISPLAY PCB : DB93-04329A
Location No. Code No. Description Specification Q’ty SNA/SA
D901 0401-000005 DIODE-SWITCHING 1N4148,75V,150mA,DO-35,TP 1 SNA
LED93 0601-001373 LED ROUND,RED,3MM`,630NM
1 SNA
LED92 0601-001375 LED ROUND,GRN,3mm,570nm,3.8x5.3mm
1 SNA
LED91 0601-001377 LED ROUND,YEL,3mm,585nm,3.8x5.3mm
1 SNA
K1 3404-001220 SWITCH-TACT 12V,50mA,160gf,6.1x6.1x5.0mm,SPST
1 SNA
CN953 3711-004068 HEADER-BOARD TO CABLE BOX,5P,1R,2MM,ANGLE,SN,WHT
1 SNA
PCB DB41-00545A PCB MAIN-DISPLAY AQV12JAKCV,FR-1,1,1.0,1.6T,-,Q,30,-,-
1 SNA

Samsung AQ18VBA Specifications

General

Brand	Samsung
Model	AQ18VBA
Category	Air Conditioner
Language	English
