 OUTDOOR MAIN PCB : DB93-05543C(AQV09NSAX)
DB93-05543D(AQV12NSAX)
6-4
Electrical Parts List
Location No. Code No. Description Specification Q’TY SA/SNA
D451,D452,D453,D454 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34,TP RLS4148
4 SNA
D104,D105,D106,D301 0402-001427 DIODE-RECTIFIER;ES1D,200V,1A,DO-214AC,TP ES1D 4 SNA
D102,D107,D401,D402,D403 0402-001429 DIODE-RECTIFIER;US1J,600V,1A,DO-214AC,TP US1J
5 SNA
ZD31 0403-001492 DIODE-ZENER 1N4756A 1 SNA
ZD451,ZD452,ZD501,ZD502 0403-000258 DIODE-ZENER;MMBZ5232B,5%,225mW,SOT-23,TP MMBZ5232B 4 SNA
ZD11 0403-001499 DIODE-ZENER;MMSZ5252,5%,500MW,SOD-123,TP MMSZ5252BD4
1 SNA
D201 0407-000123
DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT-
23,TP
KDS184
1 SNA
Q301,Q302,Q801,*Q902 0504-000127
TR-DIGITAL;FJV3102RMTF,NPN,200MW,10K/
10K,SOT-23,T
FJV3102RMTF
3 SNA
IC55,IC56 0506-000175 TR-ARRAY;2003,NPN,7,1W,SOP-16,ST,1000 ULN2003D013TR
2 SNA
Q803 0508-001132 TR-IGBT;-,600V,40A,2.6V,1200UJ,160W,TO-3P SGH40N60UF 1 SNA
LED2 DB98-16600A ASSY-LED GREEN;---------------------------------- TLPG5600 1 SNA
LED1 DB98-16601A ASSY-LED RED;---------------------------------- TLPR5600
1 SNA
LED3 DB98-16602A ASSY-LED YEL;---------------------------------- TLPY5600 1 SNA
IC12,IC31,IC32 0604-001172 PHOTO-COUPLER;TR,100-300,200mW,SOP,TP TLP181-GRH-TPL 3 SNA
IC21 1202-000104
IC-VOLTAGE COMP.;393,SOP,8P,150MIL,DUAL,36V,C
MO
KIA393F
1 SNA
IC19 1203-000274 IC-POSI.FIXED REG.;7805,TO-220,3P,-,PLASTIC,4.8/5 KA7805A 1 SNA
IC13 1203-002948
IC-POSI.ADJUST REG.;TL431ACD,SOP,8P,4.9X3.9MM,
PLA
TL431ACD
1 SNA
R301,R307 2003-000685 R-METAL OXIDE(S);4.7Kohm,5%,2W,AA,TP,4x12mm 4.7K-J 2 SNA
R107 2003-000699 R-METAL OXIDE(S);470ohm,5%,1W,AA,TP,3.3x9mm 470-J 1 SNA
R101 2003-000855 R-METAL OXIDE(S);47Kohm,5%,3W,AA,TP,6x16mm 47K-J 1 SNA
R418 2006-001013 R-CEMENT;0.02ohm,5%,7W,CA,BK,35x9.5x9.5mm 0.02-J
1 SNA
R308 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 0-J 1 SNA
R419,R420,R421,R422,R423,R
424,R425
2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 100-J
7 SNA
R505,R506,R508,R553 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 330-J
4 SNA
R303,R304,R323,R342 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 470-J 4 SNA
R302 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,1608 560-J 1 SNA
R207,R208 2007-000080 R-CHIP;2Kohm,5%,1/10W,TP,1608 2K-J
2 SNA
R104,R413 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 3.3K-J 2 SNA
R305,R315,R324,R325,R327,R
328,R415
2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 4.7K-J
7 SNA
R105 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608 6.8K-J 1 SNA
R552,R554,R555,R557,R558,R
560,R561,R562,R563,R573,R5
74,R902,R908
2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 10K-J 13 SNA
R601,R602 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 22Kohm
2 SNA
R306 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,1608 560-J 1 SNA
R205,R206 2007-000263 R-CHIP;1.82Kohm,1%,1/8W,TP,2012 1.82K-F 2 SNA
R805,*R901 2007-000300 R-CHIP;10Kohm,5%,1/8W,TP,2012 10K-J
1 SNA
R116 2007-000385 R-CHIP;14.3Kohm,1%,1/4W,TP,3216 14.3K-F 1 SNA
R539,R540,R541 2007-000493 R-CHIP;2.2Kohm,5%,1/8W,TP,2012 2.2K-J 3 SNA
R807 2007-000553 R-CHIP;20ohm,5%,1/4W,TP,3216 20-J
1 SNA
R502 2007-000614 R-CHIP;24Kohm,1%,1/10W,TP,1608 24K-F 1 SNA
R407,R408,R409 2007-000781 R-CHIP;33ohm,5%,1/8W,TP,2012 33-J 3 SNA
R113,R114,R115 2007-000924 R-CHIP;470Kohm,1%,1/4W,TP,3216 470K-F
3 SNA
R808 2007-000931 R-CHIP;470ohm,5%,1/8W,TP,2012 470-J 1 SNA
R806 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 47-J 1 SNA
R501,R504 2007-000962 R-CHIP;5.1Kohm,1%,1/10W,TP,1608 5.1K-F
2 SNA
R462,R463,R464 2007-000987 R-CHIP;5.6ohm,5%,1/8W,TP,2012 5.6-J 3 SNA
R103 2007-001118 R-CHIP;680ohm,5%,1/8W,TP,2012 680-J 1 SNA
