Electical Parts List
Samsung Electronics
6-7
OUTDOOR MAIN PCB DB93-07112G(AQV18**),DB93-07112H(AQV24**)(cont.)
LOCA. CODE DESC_SPEC PARA 1 PARA 2
18K 24K
DB93-07112G DB93-07112H
R510 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608 1M-J 1/10W,1608 11
R102 2007-000111 R-CHIP;6.8ohm,5%,1/10W,TP,1608 6.8-J 1/10W,1608 11
R408,R409,R410 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 33-J 1/10W,1608 3 3
R301 2007-000116 R-CHIP;120ohm,5%,1/10W,TP,1608 120-J 1/10W,1608 11
R115 2007-000385 R-CHIP;14.3Kohm,1%,1/4W,TP,3216 14.3K-F 1/4W,3216 11
R502,R515 2007-000455 R-CHIP;18Kohm,1%,1/10W,TP,1608 18K-F 1/10W,1608 2 2
R706,R707,R708 2007-000512 R-CHIP;2.4Kohm,5%,1/10W,TP,1608 2.4K-J 1/10W,1608 3 3
R807 2007-000553 R-CHIP;20ohm,5%,1/4W,TP,3216 20-J 1/4W,3216 11
R503,R514 2007-000614 R-CHIP;24Kohm,1%,1/10W,TP,1608 24K-F 1/10W,1608 2 2
R112,R113,R114 2007-000924 R-CHIP;470Kohm,1%,1/4W,TP,3216 470K-F 1/4W,32163 3
R412 2007-000929 R-CHIP;470ohm,1%,1/10W,TP,1608 470-F 1/10W,1608 11
R806 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 47-J 1/4W,3216 11
R511,R910,R911,R912 2007-000965 R-CHIP;5.1Kohm,5%,1/10W,TP,1608 5.1K-J 1/10W,1608 4 4
R907,R908,R909 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608 8.2K-J 1/10W,1608 3 3
R900,R901,R902,R903,
R904,R905,R906
2007-001318 R-CHIP;1Kohm,5%,1/4W,TP,3216 1K-J 1/4W,3216
77
R201,R202,R206,R207 2007-002667 R-CHIP;90.9Kohm,1%,1/4W,TP,3216
90.9K-F 1/4W,32164 4
R106,R203,R204 2007-007342 R-CHIP;1.82Kohm,1%,1/10W,TP,1608 1.82K-F 1/10W,1608 3 3
R105 2007-007445 R-CHIP;9.09Kohm,1%,1/10W,TP,1608 9.09K-F 1/10W,1608 11
R116,R117,R118 2007-008261 R-CHIP;150Kohm,1%,1/2W,TP,5025 150K-F 1/2W,5025 3 3
C307,C308,C309,
C310
2201-000154
C-CERAMIC, DISC;10 NF,+80-
20%,2KV,Y5P,TP,20X5MM,7.5
10nF 2KV 44
C105,C106
2201-000322
C-CERAMIC,DISC;2.2NF,10%,2KV,Y5P,TP,
13X5MM,10
2.2nF 2KV 22
C411,C412,C413,C414,
C415,C416
2203-000125 C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,- 1.2nF 50V,1608 6 6
C201,C203,C204,C205,
C301,C451,C452,C453,
C454,C567,C603,C607,
C801,C900,C901,C902,
C907,C908
2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608,- 10nF 50V,1608 18 18
C108 2203-001414 C-CER,CHIP;330NF,10%,50V,X7R,TP,2012 330nF 50V,2012 11
C318,C319,C320,C321 2203-002002 C-CER,CHIP;33pF,5%,50V,NPO,BK,1608,- 33pF 50V,1608 4 4
C109,C112,C116,C117,
C121,C202,C302,C303,
C304,C305,C306,C404,
C405,C406,C407,C408,
C409,C410,C417,C418,
C501,C502,C503,C504,
C505,C506,
C507,C508,
C509,C510,C511,C512,
C513,C553,C554,C555,
C556,C560,C561,C563,
C565,C568,C570,C575,
C576,C706,C3011
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608,
-
100nF 50V,1608 47 47
C419,C420 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,1608 22nF 50V,1608 2 2
C113,C122,C802 2203-005261 C-CER,CHIP;1000nF,10%,25V,X7R,-,3216 1000nF 25V,32163 3
C008 2301-000141 C-F I L M ,LEAD-
PEF;10nF,10%,630V,TP,16x11x7.5mm,5
10nF 630V1 1
C422,C803 2306-000123 C - F I L M ,LEAD-
PPF;100nF,5%,630V,BK,26x16.5x8.5,2/
100nF,5%,630V,17x12x6,15mm
100nF 630V 22
C123 2401-000303 C-AL;100uF,20%,25V,GP,TP,6.3x11,5 100uF 25V1 1
C552,C559,C562,C564,
C569,C574,C577
2401-000493 C-AL;10uF,20%,50V,LZ,TP,5x11mm,5mm
,105
10uF 50V 77
C114,C421 2401-002274 C-AL;220uF,20%,35V,WT,TP,8x11.5mm,5
,105
220uF 35V 22
C107,C118,C401,C402,
C403
2401-002438 C-AL;47μF,20%,50V,WT,TP,6.3x11,5mm,1
05
47uF 50V 55
C104 2401-003541 C-AL;10uF,20%,450V,WT,TP,12.5x20mm,
5
10uF 450V1 1
C110,C119,C805 2401-003585 C-AL;220uF,20%,35V,WT,TP,8x11.5mm,5
,105
220uF 35V 33
SA/SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
To Next Page
