48
4. Combination Table4. Combination Table
4-3 AJ052TXJ3KG/EU
COOLING
Outdoor unit A B C
Cooling Capacity Capacity
Power
Consumption
Current Efc. NOM.
Cooling.
At 35℃/27℃
SEASONAL
EFFICIENCY
(ACCORDING
EN14825)
SEER
Qce
W W W A
A B C MIN STD MAX MIN STD MAX MIN STD MAX EER Class kWh
AJ052TXJ3KG
2 Unit
7 7 2000 2000 1100 4000 4800 320 1020 1630 2 4.5 7. 5 3.92 A++ 8.08 173
7 9 2040 2560 1100 4600 5520 320 1170 1850 2 5.2 8.5 3.93 A++ 7. 73 208
7 12 1820 3180 1100 5000 6290 320 1260 2000 2 5.6 9.2 3.97 A++ 8.15 215
7 18 1490 3710 1200 5200 6600 320 1300 2040 2 5.7 9.3 4.00 A++ 7.85 232
9 9 2500 2500 1100 5000 5800 320 1160 1980 2 5.1 9.1 4.30 A+++ 8.51 206
9 12 2080 2920 1100 5000 6400 320 1250 2020 2 5.5 9.2 4.00 A++ 8.16 214
9 18 1730 3470 1200 5200 6800 320 1300 2070 2 5.7 9.5 4.00 A++ 7.85 232
12 12 2600 2600 1100 5200 6560 320 1300 2040 2 5.7 9.3 4.00 A++ 8.16 214
3 Unit
7 7 7 1730 1730 1740 1450 5200 6380 330 1280 2020 2 5.7 9.2 4.06 A++ 7.6 8 237
7 7 9 1600 1600 2000 1450 5200 6490 330 1290 2040 2 5.7 9.3 4.03 A++ 7.67 237
7 7 12 1390 1390 2420 1450 5200 6800 330 1270 2070 2 5.6 9.5 4.09 A++ 7. 6 9 237
7 9 9 1480 1860 1860 1450 5200 6600 330 1260 2040 2 5.6 9.3 4.13 A++ 7. 7 236
7 9 12 1300 1630 2270 1450 5200 6800 330 1270 2070 2 5.6 9.5 4.11 A++ 7.69 237
9 9 9 1730 1730 1740 1450 5200 6800 330 1250 2070 2 5.5 9.5 4.16 A++ 7. 7 236
9 9 12 1530 1530 2140 1450 5200 6800 330 1250 2070 2 5.5 9.5 4.16 A++ 8.08 225
HEATING
Outdoor unit A B C
Heating
Capacity
Capacity
Power
Consumption
Current Efc. NOM.
Heating.
At 7℃/20℃
SEASONAL
EFFICIENCY
(ACCORDING
EN14825)
SCOP
P
design
Qhe
W W W A
A B C MIN STD MAX MIN STD MAX MIN STD MAX COP Class kW kWh
AJ052TXJ3KG
2 Unit
7 7 2200 2200 950 4400 5060 280 1150 1510 1.7 5.4 6.9 3.83 A+ 4.40 3.05 970
7 9 2040 3060 950 5100 5870 280 1320 1830 1.7 6.1 8.4 3.86 A+ 4.35 4.21 1352
7 12 1990 3610 950 5600 6440 280 1450 1860 1.7 6.7 8.5 3.86 A+ 4.34 4.60 1484
7 18 1610 4390 950 6000 6900 280 1570 1860 1.7 7.2 8.5 3.82 A+ 4.27 4.28 1401
9 9 2900 2900 950 5800 6300 280 1510 1910 1.7 6.9 8.7 3.84 A++ 4.60 4.60 1400
9 12 2620 3180 950 5800 6300 280 1510 1910 1.7 6.9 8.7 3.84 A+ 4.34 4.60 1484
9 18 2240 4060 950 6300 7300 280 1640 1830 1.7 7. 5 8.4 3.84 A+ 4.27 4.28 1401
12 12 2950 2950 950 5900 6880 280 1530 1860 1.7 7.0 8.5 3.86 A+ 4.34 4.60 1484
3 Unit
7 7 7 1930 1930 1940 1000 5800 6760 280 1500 1840 1.7 6.9 8.4 3.87 A+ 4.30 4.60 1497
7 7 9 1690 1690 2520 1000 5900 6840 280 1550 1840 1.7 7.1 8.4 3.81 A+ 4.30 4.60 1497
7 7 12 1650 1650 3000 1000 6300 7300 280 1560 1830 1.7 7.1 8.4 4.04 A+ 4.30 4.60 1497
7 9 9 1500 2250 2250 1000 6000 6920 280 1500 1840 1.7 6.9 8.4 4.00 A+ 4.30 4.60 1497
7 9 12 1460 2190 2650 1000 6300 7300 280 1530 1830 1.7 7.0 8.4 4.12 A+ 4.30 4.60 1497
9 9 9 2100 2100 2100 1000 6300 7300 280 1320 1830 1.7 6.1 8.4 4.77 A+ 4.30 4.60 1497
9 9 12 1850 1850 2600 1000 6300 7300 280 1320 1830 1.7 6.1 8.4 4.77 A+ 4.30 4.60 1497
NOTE
1
EER and COP declared only for the purpose of tax deductions in force at the time of the creation of this catalog.
2
The above is the value for connecting with the following indoor units.
- Wind Free(PRM) : AR07TXCAAWK, AR09TXCAAWK, AR12TXCAAWK
3
You can not connect a single unit.
4
Power consumption include indoor unit power.
