Samsung AR18HSFSAWKNEU - Electrical Parts List; Indoor Main PCB Component List

Samsung Electronics 6-1
6. Electrical Parts List
6-1 INDOOR MAIN PCB (DB92-02873A)
Parts Code Design Loc Parts Description Quantity
0202-001338 SOLDER-BAR SOLDER-BAR 0.17
0202-001463 SOLDER-WIRE SOLDER-WIRE 1.51
0204-004665 FLUX FLUX 0.14
0204-005794 SOLVENT SOLVENT 1
0502-000245 Q701 TR-POWER 1
1405-001239 VA71 VARISTOR 1
2301-002032 XC71 C-FILM,LEAD-PPF 1
2301-002032 XC72 C-FILM,LEAD-PPF 1
3002-001139 BZ61 BUZZER-PIEZO 1
3711-000177 CN21 HEADER-BOARD TO CABLE 1
3711-000203 CN75 HEADER-BOARD TO CABLE 1
3711-000296 CN72 HEADER-BOARD TO CABLE 1
3711-002001 CN31 HEADER-BOARD TO CABLE 1
3711-003404 CN71 HEADER-BOARD TO CABLE 1
3711-003845 CN91 HEADER-BOARD TO CABLE 1
3711-004122 CN32 HEADER-BOARD TO CABLE 1
3711-004236 CN43 HEADER-BOARD TO CABLE 1
3711-005096 CN63 HEADER-BOARD TO CABLE 1
3711-005097 CN62 HEADER-BOARD TO CABLE 1
3711-005504 CN51 HEADER-BOARD TO CABLE 1
DB27-00096A FT71 COIL CHOKE 1
DB67-00942A VA71-1 CAP 1
DB94-04097A ASSY PCB AUTO 1
0501-000362 Q801 TR-SMALL SIGNAL 1
1404-001194 PTC2 THERMISTOR-PTC 1
3601-001765 F701 FUSE-ETC 1
3711-000024 CN76 HEADER-BOARD TO CABLE 1
3711-000941 CN81 HEADER-BOARD TO CABLE 1
3711-000998 CN77 CONNECTOR-HEADER 1
3711-000999 CN61 HEADER-BOARD TO CABLE 1
DB94-04098A ASSY PCB SMD 1
0202-001459 SOLDER-CREAM SOLDER-CREAM 0.32
0402-001741 D701 DIODE-RECTIFIER 1
0406-001204 CD81 DIODE-TVS 1
0406-001204 CD82 DIODE-TVS 1
0406-001204 CD83 DIODE-TVS 1
0501-000465 Q702 TR-SMALL SIGNAL 1
0504-001080 Q601 TR-DIGITAL 1
0504-001080 Q802 TR-DIGITAL 1
0506-000175 IC05 TR-ARRAY 1
0506-000175 IC06 TR-ARRAY 1
0604-001002 PC03 PHOTO-COUPLER 1
0604-001002 PC04 PHOTO-COUPLER 1
0604-001002 PC05 PHOTO-COUPLER 1
0801-000393 IC08 IC-CMOS LOGIC 1
1006-001325 IC07 IC-BUS TRANSCEIVER 1
1202-000104 IC11 IC-VOLTAGE COMP. 1
1203-006245 IC03 IC-VOL. DETECTOR 1
1203-007526 IC02 IC-POSI.FIXED REG. 1
2007-000029 R850 R-CHIP 1
2007-000029 R851 R-CHIP 1
2007-000067 R713 R-CHIP 1
2007-000072 R717 R-CHIP 1
2007-000076 R601 R-CHIP 1
2007-000076 R602 R-CHIP 1
2007-000076 R716 R-CHIP 1
2007-000078 R703 R-CHIP 1
2007-000078 R706 R-CHIP 1
