Samsung AR18HSFSAWKNEU - Outdoor PCB

Samsung Electronics 8-3
2
EARTH - CN003
#1 : EARTH
1
TB-N - CN001
#1 : N
3
TB-L - CN002
#1:L
5
CN030 - 4-WAY
#1,#3 : AC220~240V
4
CN051/052 - REACTOR
#1:REACTOR1
#1:REACTOR2
14
CN901 - FAN MOTOR
#1 : DC 310~340V
#2 : N.C
#3 : AGND
#4 : DC 15V
#5 : FAN RPM
#6 : FAN FEEDBACK
6
CN251 - TEMP SENSOR
#1, #2 : OUT SENSOR
#3, #4 : DISCHARGE SENSOR
16
CN301 - COMMUNICATION
#1:F1
#2:F2
CN152 - SMPS IN
#1 : 12V
#2 : GND
#3 : 5V
U/V/W - COMP
U:U
V:V
W:W
CN503-EEV
#1~#4 : EEV SIGNAL
#5 : 12V
CN201 - DOWNLOAD-MAIN
#1~#10 : DOWNLOAD
CN551 - DOWNLOAD-INV
#1~#10 : DOWNLOAD
Outdoor PCB
10 11 15
17
12
CN551 - DOWNLOAD-INV
CN153 - SMPS IN 15V
13
