21
SAMSUNG ELECTRONICS
4-1. Indoor Unit
No. Parts Procedure Remark
1 PANEL-FRONT 1) Stop the driving of air conditioner and
shut off main power supply.
2) Detach FILTER PRE from the PANEL
FRONT.
3) The COVER PANEL is xed to body by
hooks in center and side area.
4) Separate the hook pulling end of the
COVER PANEL as shown in gures.(Watch
out for the damage of hooks)
To Next Page
