Samsung AVMCH052EA4 - Side View; Front View; Centralized Controller

Centralized Controller
The centralized controller is an optional accessory and it is installed on the wall.
To use the centralized controller, refer to an appropriate manual.
E-8
Operating lamp
All On button
All Off button
On/Off indicators
On/Off buttons
Index
◆ The operating lamp comes on even when only one air conditioner
connected to the centralized controller is operating.
NN
NN
oo
oo
tt
tt
ee
ee
Front View
Operating Mode Switch
COOL
AUTO
HEAT
◆ Choose the appropriate operating mode with the Operating Mode Switch
that enables the user to choose between the Cool/Auto/Heat mode.
◆ The heating mode( ) is not selected in cooling only models.
NN
NN
oo
oo
tt
tt
ee
ee
Side View
