Parts and Dimensions
English
Installation
Parts and Dimensions
Control box parts diagram
<AVR-M100JHAX>
Sub PCB assembly
Fuse
Transformer
Relay
Terminal block
<AVR-M100FHAX>
Sub PCB assembly
Fuse
Relay
Terminal block
Unit: mm (inch)
120 (4.72)
145 (5.71)
376 (14.8)
60 (2.36)
39 (1.54)
Accessories
Product Body (1) Installation Guide (1)
Bracket Holder (1) M4 x L12 Screw (5)
