Air Conditioning Unit - Main Parts, Buttons and Display
Air inlet (inside)
Air outlet
Air filter
(The air filter is
located inside)
Air outlet
Outer air flow blades
(Right/left orientation)
Inner air flow blades
(Up/down orientation)
Air inlet (Outside)
The type of the power plug
may differ according to the
type of local power supply.
◆
The power plug may be not supplied
depending on the model.
Power plug
Power cable
Power cable connection
should be committed to
an installation engineer.
Blue Brown
Yellow/Green
Main Power
Earth
Temperature/Timer/
Fan speed settings
Temperature
adjustment buttons
Remote control sensor
Fan speed adjustment button
Energy Saver indicator
Timer/Sleep indicator
On/Off button
Operating mode selection
button
(COOL, FAN)
Timer setting button
❄ The design and shape are subject to
change according to the model.
E-4
