Exploded View and Parts List
■Part List (Type "A" )
No Description Code No. Specification
Q'TY
AZ09AATEA AZ09FATEA
1 INLET GRILLE DB64-10158A HIPS 1 -
DB64-00104A HIPS - 1
DB64-00014F HIPS - -
2 ASS'Y PANEL FRONT DB92-70096F A-TYPE 1 -
DB92-00052A F-TYPE - 1
2-1 FILTER DB63-30158C A-TYPE 1 -
DB74-00005C F-TYPE - 1
2-2 PANEL-FRONT DB64-70093A A-TYPE 1 -
DB64-00167A F-TYPE - 1
2-3 BLADE-H DB66-30191A A-TYPE 1 -
DB66-00053A F-TYPE - 1
3 EVAPORATOR DB96-01971A 2R×12S,FP1.2 1 1
4 ARM BLADE DB66-70031A PS,BLK 1 1
5 BLADE-V DB66-30211B PP,SC-97525R 1 1
6 FRAME-BLADE DB90-00508B ASS'Y 1 1
6-1 LEVER-DAMPER DB66-00278A HIPS 1 1
7 PLATE-EVAP CASING DB61-00689A ASS'Y,SGCC-M 1 1
8 PLATE-PARTITION DB71-00068B ASS'Y,SGCC-M 1 1
9 CASE-BLOWER DB90-00779A ASS'Y 1 1
10 NUT-FRANGE DB60-30004A M6,YEL 1 1
11 BLOWER DB67-00099A ABS OD Φ180 1 1
12 MOUNTER MOTOR DB61-00690A SGCC-M,T1.0 1 1
13 MOTOR DB31-00140C YGN61-6C 1 1
14 ASS'Y CASE EVAP DB90-00539B ASS'Y,PP 1 1
15 FAN PROPELLER DB67-50077A ABS,YEL 1 1
16 NUT-FRANGE DB60-30020A M6,LEFT 1 1
17 CASE-COND DB61-00423A PP,WHT 1 1
18 BASE DB90-00544A ASS'Y,SC94445T 1 1
19 CONDENSER DB96-02099A 2R×12S,FP1.5 1 1
20 COMPRESSOR 44B092JX1EF 240V/50Hz 1 1
21 ASSY-4-WAY DB96-01863A ASSY 1 1
22 ASSY-CHECK V/V DB96-01862A ASSY 1 1
24 NUT-FRANGE DB60-30001A M5,YEL 1 1
25 COVER TERMINAL DB63-10026A NORYL,BLK 1 1
26 O.L.P DB47-20057R MRA12054-12008 1 1
27 GASKET DB63-20003A EPDM,T0.8 1 1
28 NUT WASHER DB60-30028A M8,ZPC 3 3
29 GROMET ISOLATOR DB73-00070A NR 35 3 3
30 ASS'Y-CABINET DB90-00701B ASS'Y 1 1
31 ASS'Y-CONTROL DB93-01414A 240V/50Hz 1 1
31-1 SWITCH MEMBRANE DB34-00026B 99.1*134.5 1 1
31-2 PANEL CONTROL DB64-00259B HIPS,T2.0 1 1
31-3 ASSY MAIN PCB DB93-00407H HEAT PUMP 1 1
31-4 CASE CONTROL UP DB61-00419A SGCC-M,T0.7 1 1
31-5 SWING MOTOR DB31-00084B M2LJ49ZV32 1 1
31-6 CAPACITER(C-OIL) 2501-001237 35µF 450VAC× 1
31-7 CLIP CAPACITOR DB65-10008B SGCC-M,T0.7 1 1
31-8 POWER CORD DB39-00348A 250V,16A 1 1
31-9 CAPACITER(C-FILM) 2301-001369 3µF 450VAC× 1
31-10 TRANSFORMER DB26-00006E AC230V,50/60HZ 1 1
31-11 CASE CONTROL LOW DB61-00417A SGCC-M,T0.7 1 1
31-12 THERMISTOR DB32-10051E 10K/25,-,3435K 1 1
31-13 THERMISTOR COND DB32-10045F 4100,10K,25,-20~70 1 1
32 TRAY DRAIN DB63-00296A HIPS,T1.5 1 1
33 ASSY REMOCON DB93-00284L W-RAC,ARH-700 1 1
Samsung Electronics 6-2
