Exploded View and Parts List
■Part List (Type "C" )
No Description Code No. Specification
Q'TY
AZ18AAMEB AZ18FAMEB
1 ASSY PANEL-FRONT DB92-00067A F-TYPE,ASSY - 1
DB92-70101D A-TYPE,ASSY 1 -
1-1 GRILLE-AIR INLET DB64-00178A F-TYPE,HIPS - 1
DB64-10163A A-TYPE,HIPS 1 -
1-2 GUARD AIR-FILTER DB63-00100C F-TYPE,ZENO BLUE - 1
DB63-30167B A-TYPE,ABS(SF) 1 -
1-3 BLADE-H DB66-00120A F-TYPE,C-PP - 1
DB66-30205A A-TYPE,C-PP 1 -
1-4 PANEL-FRONT DB64-00177A F-TYPE,HIPS - 1
DB64-70102A A-TYPE,HIPS 1 -
2 ASSY BASE DB90-00304E M-P/J,48B DRAIN 1 1
3 TRAY-DRAIN DB63-40019A 30FOAM-PS 1 1
4 ASSY EVAP DB96-01038B 3R×15S 1 1
5 MOUNT MOTOR DB61-00440A SGCC-M,T1.2 1 1
6 MOTOR FAN DB31-00075H YSK150-4L 1 1
8 PLATE-EVAP CASING DB96-00026A ASSY 1 1
9 BLOWER DB67-00096A ABS+G/F20%,M-P/J 1 1
9-1 NUT-WASHER DB60-30002A M6 1 1
10 CASE EVAP DB61-10182A 30FOAM-PS 1 1
11 COVER-EVAP DB90-40174A ASSY,PP,T2.5 1 1
12 PLATE-PARTITION DB70-10679A SGCC-M,T0.8 1 1
13 CASE COND DB61-00448A PP(TALC),T2.5 1 1
14 FAN-PROPELLER DB67-00047A ABS,M-P/J 1 1
14-1 NUT-WASHER DB60-30004A M6,SM20C 1 1
15 ASSY COND DB96-01166A 2R×16S 1 1
16 TUBE CAPILLARY DB62-00594A 14K 1 1
17 ASSY-4-WAY DB62-00593C ASSY 1 1
18 CHECK V/V DB62-00595B ASSY 1 1
19 NUT-FLANGE DB60-30001A M5,-,SM20C 1 1
20 COVER-TERMINAL DB63-10026A NORYL 1 1
21 O.L.P DB35-00011E MRA12147-12007 1 1
22 NUT-WASHER DB60-30028A HEX,2C,M8,ZPC 3 3
23 GROMMET ISOLATOR DB73-10004B EPDM 3 3
24 COMPRESSOR 48B180JV2EH 240V/50Hz 1 1
25 CABINET DB90-00311B ASSY,SECC-P,SC-94445T 1 1
26 GASKET DB63-20003A EPDM RUBBER 1 1
27 ARM BLADE DB66-00186A POM 1 1
31 ASSY CONTROL E DB93-01665B ASSY 1 1
31-1 SWITCH MEMBRANE DB34-00026K 99.1×140.2 1 1
31-2 PANEL CONTROL DB64-00261A HIPS,T2.5 1 1
31-4 ASSY MAIN PCB DB93-00407H HEAT PUMP 1 1
31-5 CASE CONTROL UP DB61-00419A SGCC-M,T0.8 1 1
31-6 SWING MOTOR DB95-20065F M2LJ49ZU39 1 1
31-7 CAPACITER(C-OIL) 2501-001238 40µF 450VAC× 1
31-8 CLIP CAPACITOR DB65-10008B SGCC-M,T0.8 1 1
31-10 POWER CORD DB39-00348A 250V,16A 1 1
31-11 CAPACITER(C-FILM) 2301-001367 6µF 450VAC× 1
31-12 TRANSFORMER DB26-00006E AC230V,50/60HZ 1 1
31-13 CASE CONTROL LOW DB61-00417A SGCC-M,T0.8 1 1
31-14 THERMISTOR DB32-10051E 10K/25,-,3435K 1 1
31-15 THERMISTOR COND DB32-10045H 4100,10K,25,-20~70 1 1
32 LEVER-DAMPER DB66-70024A HIPS,T2.5 1 1
33 FRAME-BLADE DB90-50161E HIPS,T2.5 1 1
34 REMOCON DB93-00284L W-RAC,ARH-700 1 1
Samsung Electronics 6-6
