Installation and Operating Instructions
3-4 Samsung Electronics
Key operational function Key Type
* In case of above situation, when “increase / decrease” key is pressed by remocon,
* warning sound is generated.
Temperature
*
If operation is OFF, it is considered as an invalid key.
MEMBRANE
(▲, ▼)
*
In case of “FAN” mode operation, it is considered as an invalid key.
KEY PAD
*
Continuous operation is available.
Air swing motor operation and stop.
MEMBRANE
*
Once ON Air swing motor operation. Another ON Air swing motor stop.
KEY PAD
Air swing
*
Continuous operation is not available.
*
In case of operation stop, when the fan motor is turned off it is considered as an invalid key.
Setting the on/off timer.
*
Can set “OFF TIMERHOUR” if set is operation.
*
Can set “ON TIMER HOUR” if set is not operation.
Timer
*
Once ON-standby setting TIMER : “- -” displayed. MEMBRANE
(ON/OFF)
*
In case of key pressing in status of standby setting ON/OFF TIMER. KEY PAD
(--Hr -> 1Hr -> 2Hr -> ... -> 23Hr -> 24Hr)
*
In press TIMER key countinuosly operate such the lower part.
(--Hr -> 1Hr -> 2Hr -> ... -> 24Hr -> --Hr)
SLEEP mode on and off.
*
Once ON = SLEEP mode on, Another ON = SLEEP mode off.
• Continuous operation is not available.
* In case of OFF TIMER mode, if press SLEEP mode then OFF TIMER Mode is canceled and
Sleep SLEEP Mode operates. MEMBRANE
* SLEEP Mode is not available in ON TIMER and FAN Mode. KEY PAD
* SLEEP Mode is available in cooling and heating operation mode.
Key discription
Key name
