Samsung CD Player - Rear

1.
Two-pin digital audio output terminal for use with a sound or MPEG card supporting digital audio features.
2.
Four-pin sound output terminal for use with a sound card. (refer to the sound card documentation for
further details)
3.
Master/slave select terminal.
4.
40pin host E-IDE interface connector.
5.
4pin power terminal.
(A : +5V DC)
(B : +12V DC)
Introduction
Rear
English - 8
