Samsung Electronics 7-3
7-2 Main Parts List
Ref. No. Parts No. Description Specification Q'ty Remarks
61 DE92-90019B ASSY-RACK WIRE CE124CF,HIGH,MAGENTA 1
62 DE92-90019S ASSY-WIRE RACK CE124CF,LOW 1
63 DE61-90094A HOLDER-BARBECUE PTFE,9G 1
64 DE32-10013A SENSOR-THERMISTOR PT-312-K2 1
65 4713-000168 LAMP-INCANDESCENT 230V,-,25W,ORG 1
66 DE47-40021A SOCKET-LAMP E/14(22.225) 1
67 DE61-50234A BRACKET-LAMP SECC,T0.8 1
68 DE71-60267A COVER-LAMP STS304,T0.4 1
69 DE67-40066A GLASS-PLATE TEMP-GLASS,T3.2 1
70 DE61-50282E BRACKET-HINGE U SBHG1-A,T1.2 1
71 DE61-70060A SPRING-PLATE SK-5,T0.5 1
72 DE62-90028C ADIABATIC-UPPER T6,W399,L353.8,CERAMIC,WOOL 1 C/UPP
73 DE47-20044A THERMOSTAT PW-2N,150/60,BKT23.8MM 1 GRILL
74 DE92-90100B ASSY-GUIDE AIR RE-1280/1270 1
75 DE92-90072A ASSY-BASE ROLLER RE-909CG 1
76 DE74-20045A TRAY-CERAMIC RE-909CG 1
77 DE93-90038A ASSY-B/RESISTOR FX175Z-D 1
78 DE61-50238A BRACKET-PLATE SECC.T0.6 1
79 DE64-20045A HANDLE-BARBECUE TEMPERED,SPRAY,BLK 2
80 DE74-20107A TRAY-BROILER AL,T0.8,345,345,PI345,ENAMEL,S 1
81 DE92-90009A ASSY-SPIT RACK CE124CF 1
82 DE61-30141A SUPPORTER-HEATER(B) ALUMINA,5G,RE-650 1
83 DE63-20019A GASKET-HEATER BRASS-WIRE 1
84 DE93-20013C ASSY BODY LATCH RE-1280(SAW) 1
85 DE60-60017A PIN-WIRE MSWR3,PI1.0 1
86 DE61-50165A BRACKET-HEATER MICA-SHEET,T0.5,W35,L91.5 1
87 3601-000438 FUSE-FERRULE 250V,15A,SB,CERAMIC,6.4X31.8MM 1
88 DE73-90027A FERRITE-CORE NI-ZN,T13.8,W21.0,L28.0,BNF-14 1
: Option Parts : Warning
:Electrostatically Sensitive Devices
Exploded Views and Parts List
