Oven Accessories
Depending on the model that you have purchased, you are supplied with
several accessories that can be used in a variety of ways.
VENTILATION HOLES
DOOR LATCHES
DOOR
TURNTABLE
COUPLER
ROLLER RING
SAFETY INTERLOCK
HOLES
VENTILATION
HOLES
HEATING ELEMENT
CONTROL PANEL
DOOR
HANDLE
1. Coupler , to be placed correctly over the motor shaft in the
base of the oven.
Purpose: The coupler rotates the turntable.
2. Roller ring, to be placed in the center of the oven.
Purpose:
The roller ring supports the turntable.
3. turntable, to be placed on the roller ring with the center
fitting on to the coupler.
Purpose:
The turntable serves as the main cooking
surface; it can be easily removed for cleaning.
4. Metal racks (High rack, Low rack), to be placed on the
turntable.
Purpose:
The metal racks can be used to cook two
dishes at the same time. A small dish may be
placed on the turntable and a second dish on
the rack. The metal racks can be used in
grill, convection and combination cooking.
5. Crust plate
, to be placed on the turntable .
Purpose: The crust plate is used to brown food better in
the microwave or grill combination cooking
modes and to keep pastry and pizza dough
crisp.
7. Square Metal Rack, to be placed in the supporter rack.
Purpose:
The square metal rack is used for the
convection cooking. (Refer to the page 16)
8. Square Metal Tray, to be placed in the supporter rack.
Purpose:
The square metal rack is used for the
convection cooking. (Refer to the page 16)
9. Supporter Rack, to be placed in the right and left of the
oven.
Purpose:
The square metal rack is used for the
convection cooking. (Refer to the page 16)
