Samsung CE745GR - Main Parts List

7-2 Main Parts List
7-2 Samsung Electronics
Exploded Views and Parts List
Ref. No. Parts No. Description/Specification Q'ty Remarks OLD PARTS NO.
M 1 DE70-30032X PANEL-OUTER;T0.6 W351.2 L1010 WHT-COATIN 1
M 2 DE63-90150A CUSHION-RUBBER;DFA20 T2 W100 L140 BLK 1
M 3 DE61-50323A BRACKET-UPPER;ALSTAR T0.6 W385 L205 M624 1 73011-0243-00
M 4 DE61-30008A SUPPORTER-HEATER;ALUMINA T12 CE745G 1
M 5 DE61-70060A SPRING-PLATE;SK-5 T0.5 1 76674-232-810
M 6 DE47-70072A HEATER-GRILL;230V 1100W 47.OHM 6.25 1
M 7 DE60-40009B WASHER-TEFLON;SLOT ID22.2 OD28 T1.2 TEFL 1 70534-0004-02
M 8 DE63-20017A GASKET-HEATER;BRASS T1.5 OD30.5 ID22.5 1 73404-0014-00
M 9 DE61-50021A BRACKET-FLANGE;SECC1 T0.8 32 32 1
M 10 DE61-50027A BRACKET-HEATER;BSS2-A T(1.0) W(51) L(55) 1
M 11 DE61-50025A BRACKET-EARTH;BSS2-A T1.0 CE745G 1
M 12 DE39-20058C ASSY POWER CORD;KKP-4819D/B232 250V16A L 1
M 13 DE71-60298A COVER-BACK;SECC T0.6 W273 L633 M6Q45 1 73312-0184-001
M 14 DE91-40095A ASSY NOISE FILTER;SN-E10D(N) 250V 10A “2 1
M 15 DE31-30031A FAN-MOTOR;SMF745EA 230V/50HZ ASSY-FAN-MO 1
M 16 DE47-20009A THERMOSTAT;CS-7SA(160/60)187Y 250V7.5A 1 1
M 17 DE03-30035A MAGNETRON;OM75PH((31)ESS 1 77059-0034-00
M 18 4713-001004 LAMP-INCANDESCENT;230V,-,40W,ORG,-,-,25x 1
M 19 DE71-60010A COVER-AIR;PP(TB53) T1.7 WHT 64G M745 1
M 20 DE61-50129A BRACKET-MOUNTING;SECC T0.8 W24 L316 M624 1 73013-0342-00
M 21 DE93-20001A ASSY BODY LATCH;2ND-W1 M97G45/M9745 1
M 22 DE66-90013A LEVER-DOOR;POM(F20-01) NTR MW5630T 1 71533-0015-00
M 23 DE91-70061B ASSY-H.V.FUSE;THV060T-0750-H 5KV0.75A RE 1 79163-0252-01
M 24 DE61-50106A BRACKET-HVC;SECC T0.8 W31 L125.8 1 73013-0194-00
M 25 DE91-70065A ASSY-HVD;BMP28 SEMA 12KV SUMI 1 79169-0153-00
M 26 2501-001014 C-OIL;HCH212105C 1.05UF,2100V 35X54X85,2 1
M 27 DE26-10099A TRANS-H.V;SHV-745EG1 230V 50HZ 2200V DPC 1
M 28 DE61-40017A FOOT;PP(A353) BLK MW5630T 2 73004-0007-00
M 29 DE80-10003A BASE-PLATE;SGCC1-Z T0.8 W340 L550 M745 1
M 30 DE31-10154A MOTOR-DRIVE;M2HJ49ZR02,ST-16 21V 5/6 1
M 31 DE47-20008A THERMOSTAT;CS-7S(100/60)187Y 250V7.5A 10 1
M 32 DE71-60013A COVER-CEILING;MICA T0.5 W52 L118 CE745G 1
M 33 DE61-80004A HINGE-LOWER;SCP1 T2.3 ZN-COATING BLK 1
M 34 DE61-80005A HINGE-UPPER;SCP1 T2.3 BLK ZN-COATING 1
M 35 DE47-20174A THERMOSTAT;NT-101NA 8XH 120 110 23.8MM 1
M 36 DE65-20014A CABLE CLAMP;DA-6N NY-66 1 76449-0003-00
M 37 ASSY DOOR;PUSH WHT CE745GR 1
M 38 ASSY CONTROL-BOX;230V-50HZ CE745GR(CIS) 1
M 39 DE74-20102B TRAY-COOKING;GLASS T5.0 PI288 780G M745 1
M 40 DE92-90436A ASSY-GUIDE ROLLER;MW4370W 1
M 41 DE67-60002A COUPLER;PPS 5GR BRN M97G45 1
M 42 DE74-70071A RACK-WIRE;MSWR3 PI3 PI230 HI80 SNC2 1
M 43 DE39-40409A ASSY WIRE HARNESS-E;230V50HZ M9G45 CTW 1 79204-0381-00
M 44 DE39-40568A ASSY WIRE HARNESS-A;230V50HZ CE745G/CE94 1
: Option Parts
: Warning
:Electrostatically Sensitive Devices
