Samsung CE745GR - Door Parts List; Control Parts List

Samsung Electronics 7-3
7-3 Door Parts List
Ref. No. Parts No. Description/Specification Q'ty Remarks Old Parts No.
D 1 DE64-40007A DOOR-A;ABS(VH-080) T3.0 WHT 1
D 2 DE64-40006A DOOR-KEY;POM(TC3005) T2.0 12GR BLK CE9 1
D 3 DE61-70033A SPRING-KEY;ES HSWR10 PI0.6 D6.0 L22.3 BL 1 72724-0040-00
D 4 DE67-20004D SCREEN-DOOR;PC T1.5 W173.6 L373.5 WHT CE 1
D 5 DE92-50126B ASSY DOOR-E;COATING BLK CE745G 1
D 6 DE64-40008B DOOR-C;PP T1.5 W L G BLK CE745G 1
D 7 DE01-00003B FILM-DOOR;PC T0.2 W143 L265 TRP CE745G 1
7-4 Control Parts List
Ref. No. Parts No. Description/Specification Q'ty Remarks Old Parts No.
C 1 DE66-20006A BUTTON-PUSH;RESIN-ABS(HR-0370U) P/WHT M9 1
C 2 DE61-70076A SPRING-BUTTON;HSWR PI0.6 1 76674-239-310
C 3 DE34-10007C SWITCH-MEMBRANE;PET 230V50HZ W89.7 L161. 1
C 4 DE72-70003A CONTROL-PANEL;ABS(VH-080) WHT 1
C 5 DE67-40002A WINDOW-DISPLAY;RESIN-ACRYLIC T2.3 M945(I 1
C 6 DE91-10377A ASSY P.C.B-MAIN;230V50HZ NS V.F.D CE945G 1
7-5 Body Latch Parts List
Ref. No. Parts No. Description/Specification Q'ty Remarks Old Parts No.
B 1 DE66-40001A LATCH-BODY;POM(F20-02) 40GR NTR 1
B 2 3405-000178 SWITCH-MICRO;VP-533A-OF-PS(T85) 250V,15A 1 73579-203-207
B 3 3405-000175 SWITCH-MICRO;VP-531A-OF(T85) 250V,15A,20 1 73579-203-278
B 4 3405-000178 SWITCH-MICRO;VP-533A-OF-PS(T85) 250V,15A 1 73579-203-207
B 5 DE66-90001A LEVER-SWITCH;P.O.M(F20-02) 2 6 NTR 2ND-W 1
Exploded Views and Parts List
